JMZ-1-1.5A Wire Rope Vibration Isolator 44mm Width for Industrial Engine Mounts
Maximize Equipment Protection with JMZ-1-1.5A Vibration Isolators for Low-Frequency Vibration
JMZ Series Vibration Isolators effectively address low-frequency vibration that travels long distances and attenuates slowly, making it particularly impactful for equipment and building structures. These friction damping vibration isolators from Xi'an Hoan Microwave Co., Ltd. outperform traditional solutions in critical applications.
While many elastic vibration isolators effectively isolate high-frequency vibration, they often experience resonance with low-frequency vibration, amplifying the problem. The JMZ series leverages high damping characteristics to rapidly dampen resonant amplitude and shorten system stabilization time.
Effective for both heavy industrial vibrations (from stamping equipment or compressors) and micro-vibrations (from urban rail transit), the JMZ series blocks vibration transmission paths. Ideal for protecting sensitive equipment in environments with extreme vibration requirements:
- Acoustic laboratories
- Metrology centers
- Hospital MRI rooms
Dimension Parameters
| Model | Nominal Load (kg) | B | A±0.2 | H | h±0.5 | T | d | d1 | D |
| JMZ-1-1.0A | 1.0 | 44 | 35 | 50 | 36 | SW14 | M5-7H | 5.1～5.4 | 39.5 |
| JMZ-1-1.5A | 1.5 | Same as JMZ-1-1.0A |
| JMZ-1-2.0A | 2.0 | Same as JMZ-1-1.0A |
| JMZ-1-3.0A | 3.0 | Same as JMZ-1-1.0A |
| JMZ-1-3.5A | 3.5 | Same as JMZ-1-1.0A |
Performance Characteristics
Vibration Curve
Impact Curve
Technical Parameters
| Model | Pz Nominal Load (KG) | Pz Max Deflection (mm) | Vibration (Kv) | Shock (Ks) | Resonant Frequency (Hz) | Working Temperature(℃) |
| JMZ-1-1.0A | 1.0 | 3±1.5 | ≤3.5 | 30g/11ms | ＜15 | -65～+120 |
| JMZ-1-1.5A | 1.5 | Same as JMZ-1-1.0A |
| JMZ-1-2.0A | 2.0 | 2±1.5 | Same as JMZ-1-1.0A |
| JMZ-1-3.0A | 3.0 | 3±1.5 | Same as JMZ-1-1.0A |
| JMZ-1-3.5A | 3.5 | Same as JMZ-1-1.0A |
